Albion Brass Gate Valve - ART 640LS
Durable and lightweight, this Albion valve is WRAS approved for use with both potable water and saturated steam. Featuring a built-in lockshield, it can be trusted with the task of maintaining the purity of a water supply. The body and wedge of this gate valve are made from dezincification resistant brass. Full bore with a female BSPT taper threading, this valve conforms to BS5154:1991 and can sustain high pressures and temperatures.

Summary:

• Screwed BSP Taper (ISO 7/1) or NPT(ANSI B1.20.1)
• DZR Brass Body & Wedge
• BS5154
• WRAS Approved
• Lockshield Key available separately


Usage:

• Potable Drinking Water
• Saturated steam

Specifications:
PN Rating (Pressure Nominale)
PN20

Pressure Ratings
20 Bar

Material
Brass DZR - CW602N

Connection
BSP Taper F/F Ends (ISO 7/1) or NPT (ANSI B1.20.1)

Wedge
DZR- CW602N

Bonnet
DZR - CW602N

Stem Packing
PTFE

Gland
Brass - HOb58-2

Working Temperature
-20°C to +170°C
